| SQD系列 |
所有方驱颁授均配备标准旋转自锁接头、方驱和适用于方驱的反作用力臂 |
| 技术参数 |
典型套筒
尺寸范围 |
方驱
 |
最大
扭矩
700bar |
驱动头
型号
 |
SQD-25-I驱动头及插件尺寸(mm) |
重量 |
mm |
inch |
inch |
Nm |
|
A |
B |
C |
D |
E |
G |
H |
J |
K |
L |
M |
N |
kg |
15-50 |
11/16-17/8" |
3/4" |
2045 |
SQD-25-I |
167 |
72 |
53 |
24 |
108 |
95 |
35 |
3/4" |
6 |
28 |
27 |
36 |
2.5 |
20-100 |
7/8-37/8" |
1" |
4197 |
SQD-50-I |
204 |
92 |
68 |
31 |
135 |
115 |
35 |
1" |
15 |
33 |
34 |
52 |
4.3 |
30-110 |
11/8"-43/8" |
11/2" |
6615 |
SQD-75-I |
226 |
107 |
76 |
36 |
153 |
122 |
35 |
11/2" |
12 |
43 |
39 |
64 |
6.7 |
40-120 |
15/8"-43/4" |
11/2" |
8790 |
SQD-100-I |
253 |
115 |
84 |
39 |
164 |
130 |
35 |
11/2" |
13 |
39 |
43 |
68 |
8.0 |
60-155 |
23/8"-61/8" |
11/2" |
14046 |
SQD-160-I |
272 |
134 |
100 |
48 |
178 |
150 |
50 |
11/2" |
11 |
45 |
54 |
81 |
12.0 |
80-255 |
31/8"-10" |
21/2" |
23575 |
SQD-270-I |
342 |
164 |
119 |
59 |
218 |
200 |
50 |
21/2" |
18 |
76 |
63 |
99 |
24.0 |
1)与ENERPAC联系确认套筒尺寸。2)根据螺栓(螺母)尺寸和强度确定扭矩。 |
|
| 扭矩扳手泵 |
|
Enerpac系统配套的气动及电动泵用于扭矩扳手的操作。 |
|
|
|
|
